| Other Handling Products |
Other Handling Products |
| |
|
|
| |
ASEA METAL supplies complementary industrial products in Korea to complete your piping and plant procurement. We support project-specific specifications, inspection options and export documentation.
We support outsourcing handling products in Korea for piping and maintenance projects. Typical items can be supplied to standards such as ASME B16.20, ASME B16.21 and ASME B16.11 depending on product form. Where forgings are required, materials such as ASTM A105 and ASTM A182 F316 can be matched to your specification list. We align documentation to MTC (EN 10204 3.1) and export packing requirements as requested. ASEA METAL is a Korean supplier that reviews drawings and code requirements before quotation.
Quick specs
| Typical items | Gasket, sight glass, quick opening closure, wire rod, expansion joint, cutting services, forged fitting, clad & overlay, plug |
| Supply basis | Per project specification and drawings |
| Documents | MTC (EN 10204 3.1/3.2) by request, inspection scope per order |
Request a quotation (RFQ)
Share item name, material/standard, size, quantity, documents (MTC) and destination for a quick quotation from ASEA METAL. Attach datasheet/drawing if available.
Contact / RFQ
Can you bundle multiple items into one shipment?
Yes. We can coordinate mixed items for consolidated export packing depending on lead times and inspection requirements.
Do you support inspection and documentation?
Yes. Please specify your inspection scope and document requirements (e.g., MTC) in the RFQ.
|
| |
| Technical Specifications by Product |
| |
| 1. Gasket |
| ● |
Types: Spiral-wound, ring joint (RTJ), kammprofile, soft-cut sheet, and jacketed gaskets for raised-face and ring-joint flanges. |
| ● |
Standards & ratings: Supplied per ASME B16.20, B16.21, EN 1514, JIS, and project class/pressure-temperature tables (e.g. Class 150–500). |
| ● |
Materials: Stainless windings (304/316L), flexible graphite or PTFE filler, non-asbestos sheet; MTC and traceability on request. |
|
| |
| 2. Sight Glass |
| ● |
Design: Bolted or clamp window assemblies for vessels and piping with borosilicate or toughened glass disc per pressure/temperature rating. |
| ● |
Mounting: Flanged ends to ASME B16.5 / EN 1092-1; gasket and bolting matched to flange class; optional illumination or wiper ports per drawing. |
| ● |
Documentation: Hydro test, material certs for body and glass, and third-party witness when specified in the inquiry. |
|
| |
| 3. Quick Opening Closure |
| ● |
Application: Manways and horizontal vessel heads for pig launchers/receivers, filters, and separators; quick access without full flange breakout. |
| ● |
Safety: Clamp, bayonet, or swing-bolt styles with pressure-warning devices and interlocks per ASME Section VIII and API-type practices where applicable. |
| ● |
Data for quote: Design pressure/temperature, nozzle size, corrosion allowance, and required code (ASME/API) for nozzle reinforcement review. |
|
| |
| 4. Wire Rod |
| ● |
Grades: Carbon and alloy wire rod for cold heading, mesh, or redraw; stainless grades available for corrosion-resistant applications. |
| ● |
Supply form: Mill coils with heat/lot ID; typical diameters and coil weights per mill listing—confirm target end use (fastener, wire drawing, welding wire feedstock). |
| ● |
Certs: Chemical and mechanical MTC (EN 10204 3.1) aligned to ASTM, JIS, or KS as agreed. |
|
| |
| 5. Expansion Joint |
| ● |
Types: Metal bellows for axial, lateral, and angular movement; tied or untied; internally/externally pressurized designs per EJMA-based calculation. |
| ● |
Materials: Austenitic stainless (321, 316L), high-nickel alloys for high temperature; flanges or weld ends to match piping class. |
| ● |
Inquiry data: Fluid, design/movement cycles, pressure, temperature, and connected equipment loads for spring rate and fatigue review. |
|
| |
| 6. Cutting Pipes |
| ● |
Scope: Cold cutting tools and services for pipe and prep for welding—site cuts with square, bevel-ready ends where the tool specification allows. |
| ● |
Compatibility: Carbon, stainless, and duplex pipe within stated OD/thickness ranges; confirm wall schedule and access clearance before ordering. |
| ● |
Quality: Dimensional check and NDT of weld prep can follow your ITP after cutting. |
|
| |
| 7. Forged Fitting |
| ● |
Product forms: Socket-weld and threaded forged elbows, tees, couplings, unions, caps, and bushings per ASME B16.11 and related dimensional standards. |
| ● |
Materials: Carbon (ASTM A105), low alloy, and stainless forgings (A182 F304/F316/F51, etc.) with correct marking and heat code traceability. |
| ● |
Pressure class: 2000 / 3000 / 6000 lb classes as stamped; match to piping rating and hydro test requirements. |
|
| |
| 8. Clad & Overlay |
| ● |
Processes: Weld overlay (strip or wire), roll-bonded clad plate, or in-shop built-up corrosion-resistant alloy layers on carbon or low-alloy base metal. |
| ● |
Alloys: 308L, 309L, 316L, Inconel 625, and other CRA overlays for sour service or chloride resistance per project metallurgy. |
| ● |
QA: PMI, ferrite check, UT of bond zone, and bend/shear tests per WPS/PQR documentation. |
|
| |
| 9. Plug |
| ● |
Use: Pipe and vessel plugs for hydrostatic testing, isolation, or temporary seal-off; threaded, flanged, or mechanical lock types per application. |
| ● |
Materials & pressure: Carbon steel, stainless, or brass bodies with elastomer or metal seals; rated pressure must match system test pressure and temperature. |
| ● |
Safety: Use only with retained locking devices where required; never exceed manufacturer pressure limits. |
|
| |
Related topics & terms
Quick Reference: Other Handling Products
ASEA METAL supplies handling products on an OEM (outsourcing) basis and performs strict inspection in Korea before delivery.
We issue MTC (EN 10204 3.1) from ASEA METAL with traceability documents for export projects when required.
Procurement search terms: handling products Korea supplier, ASME B16.20, ASME B16.21, ASTM A105, ASTM A182 F316, MTC EN10204 3.1.
|
| |
|
|
